12μm高性能非制冷红外探测器， NETD＜25mk
场景算法优化，支持场景自定义
D款双视场镜头25mm/50mm
激光测距1200m
RAV录像（后坐力录像）
自动防灼伤保护功能
IP67防水防尘
|
型号 |
E325 |
E335 |
E350 |
E350D |
E625 |
E635 |
E650 |
E650D |
|
探测器 |
384x288, 12μm |
384x288, 12μm |
384x288, 12μm |
384x288, 12μm |
640x512, 12μm |
640x512, 12μm |
640x512, 12μm |
640x512, 12μm |
|
帧率 |
50Hz |
50Hz |
50Hz |
50Hz |
50Hz |
50Hz |
50Hz |
50Hz |
|
NETD |
≤25mk |
≤25mk |
≤25mk |
≤25mk |
≤25mk |
≤25mk |
≤25mk |
≤25mk |
|
镜头 |
25mm(F1.0) |
35mm(F1.0) |
50mm(F1.0) |
25mm/50mm |
25mm(F1.0) |
35mm(F1.0) |
50mm(F1.0) |
25mm/50mm |
|
视场角 |
10.5°x7.9° |
7.5°x5.6° |
5.3°x3.9° |
10.5°x7.9°/5.3°x3.9° |
17.5°x13.1° |
12.5°x9.4° |
8.8°x6.6° |
17.5°x13.1°/8.8°x6.6° |
|
探测范围 |
1280m |
1800m |
2600m |
1280/2600m |
1280m |
1800m |
2600m |
1280/2600m |
|
电子变焦 |
1X/2X/4X |
1X/2X/4X |
1X/2X/4X |
1X/2X/4X |
1X/2X/4X/8X |
1X/2X/4X/8X |
1X/2X/4X/8X |
1X/2X/4X/8X |
|
存储 |
32G |
32G |
32G |
32G |
32G |
32G |
32G |
32G |
|
工作温度/湿度 |
-20℃~55℃, 90% |
-20℃~55℃, 90% |
-20℃~55℃, 90% |
-20℃~55℃, 90% |
-20℃~55℃, 90% |
-20℃~55℃, 90% |
-20℃~55℃, 90% |
-20℃~55℃, 90% |
|
尺寸 |
196x62x90(mm) |
196x62x90(mm) |
203x66x90(mm) |
212x66x90(mm) |
196x62x90(mm) |
196x62x90(mm) |
203x66x90(mm) |
212x66x90(mm) |
|
重量 |
585g |
595g |
620g |
750g |
585g |
595g |
620g |
750g |
